Main features:

 Designed for use in noisy areas and harsh environments
 Extremely robust
 Good acoustic qualities and highly visible
 Stainless steel brackets for wall mount
 High visibility yellow paint finish
 23dB noise reduction
 Telephone mounting panel 200mm deep shelf
 Popular in noisy factories such as
   newspaper print rooms.

Noise Reduction:

For external or internal use, the
RF-13 is designed to attain a high
level of noise reduction up to 23dB. Manufactured using general-purpose resin
material to BS476 Class 1 fire regulation, the RF-13 is extremely robust and
weatherproof. Inside the hood's outer shell is a perforated polypropylene lining
that houses 50mm non-hygroscopic acoustic insulation.
Fitted to the inner back wall is a stainless steel apparatus plate; beneath this plate
is a detachable GRP shelf with easy cable entry. The hood is fixed to the wall via
two stainless steel brackets that are secured through the hood's back panel
enabling a load of up to 60 kgs to be safely mounted.

Specifications :

Colour: Yellow
Dimensions: H940mm W700mm D620mm (excluding fixing brackets)
Weight -Approx 23Kg
Outer Shell & Shelf -General Purpose Resin continuous filament mat -Fire Resistance
to BS476 Part 7 Class 1 Surface Spread of Flame
Acoustic Insulation -50mm Tissue faced non hygroscopic Rockwool (RW3) density
60kg/m3
Insulation Liner -White Perforated Polypropylene 3mm thickness
Apparatus plate -316 Grade Stainless Steel 2mm thickness
Mounting Brackets -316 Grade Stainless Steel, 6mm thickness
Boxed Dimensions -980 x 800 x 680cm
Boxed Weight -Approx 26kg

Specifications :

Colour: Yellow
Dimensions: H940mm W700mm D620mm (excluding fixing brackets)
Weight -Approx 23Kg
Outer Shell & Shelf -General Purpose Resin continuous filament mat -Fire Resistance
to BS476 Part 7 Class 1 Surface Spread of Flame
Acoustic Insulation -50mm Tissue faced non hygroscopic Rockwool (RW3) density
60kg/m3
Insulation Liner -White Perforated Polypropylene 3mm thickness
Apparatus plate -316 Grade Stainless Steel 2mm thickness
Mounting Brackets -316 Grade Stainless Steel, 6mm thickness
Boxed Dimensions -980 x 800 x 680cm
Boxed Weight -Approx 26kg

Certification:

EMC: EN50121 (Railway application- Electromagnetic Compatibility)
EN55022: emissions EN55024: immunity
FCC
ITU-T Recommendations K21
